Emissions Abators

The AN5100 is effective gas abatement equipment, abating more than 90% of the EO from exhaust stream

Make it zero emission

Andersen’s emissions abators are designed to remove more than 99% of the ethylene oxide emitted from our sterilizers.

When combined with any Andersen sterilizer, our award-winning gas abatement equipment releases a fraction of a gram of EO per cycle, and less than a pound of total emissions per year, effectively making the process zero emissions. Both abators employ a dry catalyst resin that converts ethylene oxide to biodegradable organic compounds.

Our systems are recognized for using a microdose of ethylene oxide and our emissions fall well below all federal guidelines. If you choose to abate, remember we have this option for you.

Award-winning Innovation

2019 FDA Innovation Challenge 2 Winner
High Efficiency EO Sterilization Process
2020 SBA Environmental Stewardship Award
Zero Emission Technology

Emissions Abator Optional for All Andersen Sterilizers

AN5100 Abator gas abatment equipment

AN5100 EO Abator

ANPROLENE & EOGAS 4

For use with Anprolene and EOGas 4 sterilizers.

AN5200 EO Abator, gas abatement equipment

AN5200 EO Abator

EOGAS 3

For use with EOGas 3 sterilizers.

AN5100 EO Abator

Installation is Quick & Easy

The vent hose from the sterilizer connects to the AN5100 Abator, which is then vented to the outside of the building for extra safety.

The AN5100 Replaceable Cartridge Abator is controlled and monitored through a single wire connection to the sterilizer. Accurate tracking of gas usage will automatically alert the operator when it approaches time to change the cartridge.

AN5100 Replacement cartridge
The AN5100.00 Replacement Cartridge is easy to replace.

Replacement Cartridge

After 200 cycles, the gas abatement equipment will alert the operator that it’s time to change the cartridge. The old cartridge can be disposed of with ordinary waste, if local regulations permit, or it can be returned to Andersen for disposal. The AN5100.00 Replacement Cartridge is available via standard ground shipping.

AN5100 Specs

Note: All AN74j, AN75 and EOGas 4 Sterilizers are abator-ready. AN74i/ix units starting with lot number 243588/243583 (9/14/2004) are abator-ready.

AN5100 Specs

Dimensions17″ L x 12″ W x 26.5″ H
Power115V, 4 amps or
230V, 2 amps
Operating weight67 lb
AN5100 Abator Order #:115V – AN5100.01
230V – AN5100.11
Replacement Cartridge Order #:AN5100.00
Indoor useTemperature range 68ºF – 91ºF
AN5200 EO Abator

Installation is Quick & Easy

Installation is simple, as the abator easily attaches to new EOGas 3 sterilizers. At time of abator installation, the EOGas 3 extractor must be reprogrammed, requiring Andersen Field Service support.

Replacement Drum

The AN5200 Abator Drum is available via standard ground shipping. It is designed to abate up to 1,800, 10.5g EO gas cartridges before needing to be replaced. Spent drums are non-hazardous and can be disposed of with ordinary waste, if local regulations permit. Drums can also be returned to Andersen for disposal.

AN5200 Specs

Note: If your EOGas 3 sterilizer was built in 2018 or before, we have an alternate abator option for you. Be sure to mention your sterilizer’s age when ordering your abator so it will be compatible.

AN5200 EO Abator Specs

Dimensions27″ L x 21″ W x 46″ H
PowerN/A
Cabinet weight100 lb
AN5200 Abator Order #:AN5200.98
Replacement Drum Order #:AN5200.00
Indoor useTemperature range 68ºF – 91ºF
AltitudeUp to 6,562 feet

Why Ethylene Oxide (EO/EtO) Sterilization?

Ethylene oxide is the gold standard in sterilization. It offers hospital-level sterility assurance (10⁻⁶) along with
unparalleled gentleness and material compatibility.
